1-Port Industrial Serial Device Server, RS-232/422/485, DB9(M)
Available on back-order
Make Serial Devices Ready to the Network
The Industrial Serial Device Server SE5901 is a cost effective gateway for Ethernet (TCP/IP) and serial signal communications; allowing almost any serial device to be connected to a new or existing Ethernet network. By encapsulating serial data and transporting it over Ethernet, SE5901 offers full duplex and bi-directional data seamlessly between the serial port and the Ethernet network.
Advanced embedded security
SE5901 embeds IPsec VPN Encryption, that allows you to tunnel your data securely throught the internet and prevent unauthorized control of your Serial Devices by malicious people.
Easy to Use
Flexible configuration options enable this unit to be setup over Ethernet by Telnet, Web Browser, or our Windows Utility. Packed in a rugged metal housing for wall or DIN-Rail mount with 9-48 VDC wide range power input, SE5901 is ideal for almost any industrial and manufacturing automation process. ATOP Virtual COM software provides a virtual environment for applications when accessing SE5901 through TCP.
Specifically Designed for Automation Fields and Harsh Environments
In industrial and manufacturing automation fields, SE5901 is used as a field device to connect the Ethernet through TCP/IP protocol directly. It is also specially designed for conjunction with PLCs, HMIs, Barcode Scanners, Data Terminals, and much more..Its design protects it from very harsh EMC and environmental conditions, making it a cost-effective choice for advanced applications.
Rugged and flexible for advanced developments
SE5901 embeds high EMC protection, wide temperature operation, programming and installation flexibility in one device. PoE versions can be powered through Power-over-Ethernet (PoE 802.3af), without additional cabling and power supply. SDK versions allow you to make use of the powerful hardware and develop your own applications on top of ATOP’s reliable SDK.
We understand that it can be difficult to find the right products for your needs. That’s why our dedicated customer support team is available to assist you in any way possible. Whether you need help selecting the best product for your application or more information on a particular device, our knowledgeable staff is here to provide you with the answers you need. Contact us today for more information about how we can help you get the products and support you need!
1-Port Industrial Serial Device Server, RS-232/422/485, Terminal Block
Available on back-order
1-port RS-232/422/485 Ind. Serial Server, DB9,PoE Pwrd
Available on back-order
1-port RS-232/422/485 Ind. Serial Server, TB,PoE Pwrd
Available on back-order
CPU | |
---|---|
Flash | |
RAM | |
EEPROM | |
Watchdog | |
Real-time Clock (RTC) | |
Buzzer | |
Console Port | |
Reset Button | |
Standards | |
Ethernet Ports | |
Power over Ethernet | |
Connector | 3-Pin 5.08mm Lockable Terminal Block, D-Sub9 RS-232/485 software selectable (DB model) 5-Pin 5.08mm Terminal Block |
Ports | |
Baud Rate | |
Data Bits | |
Stop Bits | |
Flow Control | |
USB Ports | |
Bootloader | |
Linux kernel | |
Linux toolchain | Linux 32 bits toolchain gcc (C/C++ PC cross compiler), glibc |
Linux sample code | RS232, RS485, RTC, watchdog, LED, Buzzer, Button, network socket |
Input Voltage | |
Power Consumption | |
Reverse Polarity Protection | |
Operating Temperature | -40°C~85°C (-40°F~185°F), '-40°C~85°C (-40°F~185°F) |
Storage Temperature | |
Ambient Relative Humidity | |
Housing | |
Dimensions(W x H x D) | |
Installation | |
Weight |
